OneOID无人机运行识别模块
产品概述
OneOID是零一飞行自研的无人机运行识别模块，遵守GB 46761-2025 GB 46750-2025国家标准设计，它支持蓝牙、WiFi广播式识别及网络式识别，采用CAN总线通信方式，是无人机合规飞行的必备系统。
规格参数
| 项目 | 参数 |
|---|---|
| 设计标准 | GB 46761-2025 GB 46750-2025 |
| 主处理器 | 32位RISC-V处理器 |
| 通信方式 | DroneCAN、UART（MavLink） |
| 固件 | ArduRemoteID 可固件升级 |
| 接口明细 | CAN口×1、Type-C×1 |
| 网络式运行识别 | 支持 |
| 蓝牙广播式识别 | 蓝牙5.0 ≥ 4dBm |
| Wifi广播式识别 | 支持 ≥ 18dBm |
| 内置e-SIM | 是 |
| 网络运营商 | 中国电信 |
| 输入电压 | 12-36V |
| 工作温度 | -20℃~75℃ |
| 材质 | 航空铝合金 |
| 重量 | |
| 尺寸 |
配件清单
| 项目 | 数量 |
|---|---|
| OneOID主机 | 1 |
| CAN/I2C线 | 1 |
| 串口线 | 1 |
| MCX弯公头1.4~2.4G天线 | 2 |
| 3M胶 | 2 |
| 合格证 | 1 |
